IVEX-PL-10

30x Zoom 2MP Full HD  Network Camera

The IVEX-PL-10 is a compact 30x zoom 2MP Full HD explosion-proof network bullet camera designed for reliable video surveillance in hazardous industrial environments. Its electropolished AISI 316L stainless steel housing features a weld-free lost-wax casting structure and IP67 ingress protection. Certified for Gas Zone 1 & 2 and Dust Zone 21 & 22, the camera supports IECEx, ATEX, KCs, JEPX, NEPSI and TS explosion-proof certifications. Equipped with a 1/2.8″ Sony STARVIS CMOS sensor, 30x optical zoom and 32x digital zoom, it delivers Full HD video with enhanced monitoring performance. Day & Night, WDR, digital noise reduction, intelligent motion detection, ONVIF Profile-S and PoE support make the IVEX-PL-10 suitable for demanding industrial and hazardous-area surveillance applications.

30x Zoom 2MP Full HD  Network Camera

  • Ex Certifications : IECEx / ATEX / KCs / JEPX / NEPSI / TS
  • Ex Certifications (Gas) : Ex d IIC T6 Gb, Zone 1 & 2
  • Ex Certifications (Dust) : Ex tb IIIC T85˚C Db, Zone 21 & 22
  • Electropolished AISI 316L Stainless Steel / Lost-wax casting mold structure without welds
  • Ingress Protection Rating : IP67
  • Ambient Temperature : -40°C ~ +65°C
  • Full HD 2 Megapixel, 1/2.8″ Sony STARVIS CMOS Sensor
  • Min. illumination : Color : 0.5 lux , BW : 0.005lux
  • Focal Length / Zoom : 4.3~129mm / Optical 30x , Digital : 32x
  • Day & Night (ICR)
  • WDR(Wide Dynamic Range)
  • Digital Noise Reduction (2D + 3D)
  • Privacy Mask Function
  • Intelligent Motion Detection
  • OSD Support
  • Cable Entry : 1 x 1/2″ NPT
  • ONVIF (Profile-S)
  • NDAA Compliant
  • PoE Class 3 (IEEE 802.3af) support

ITEM IVEX-PL-10
Ex Certifications IECEx / ATEX / KCs / NEPSI / JPEx / TS
Ex Certifications (Gas) Ex d IIC T6 Gb, Zone 1 & 2
Ex Certifications (Dust) Ex tb IIIC T85°C Db, Zone 21 & 22
Ingress Protection Rating IP67
Construction AISI 316L Stainless Steel
Window Tempered Glass
Ambient Temperature -40°C ~ +65°C
Operating Humidity Less than 90%RH
Dimensions 140(W) × 235.5(H) × 290.7(L) mm
Weight About 5.5 kg
Supply Voltage PoE Class 3 (IEEE 802.3af)
Cable Entry 1 × 1/2″ NPT
Image Sensor 1/2.8″ Sony CMOS Sensor
Total Pixels 1945(H) × 1109(V) = 2.16M Pixels
Effective Pixels 1945(H) × 1097(V) = 2.13M Pixels
Scanning System Progressive Scan
Resolution 1080p/60(50)fps, 1080p/30(25)fps, 720p/60(50)fps, 720p/30(25)fps
Min. Illumination Color: 0.5 lux / BW: 0.005 lux
S/N Ratio More than 50dB (AGC Off)
Lens Type 30x Day & Night Zoom Lens
Zoom Ratio Optical 30x / Digital 32x
Focal Length f = 4.3mm ~ 129.0mm
Angle of View (D/H/V) – Wide 72.9° / 65.1° / 38.4° (±5%)
Angle of View (D/H/V) – Tele 2.4° / 2.3° / 1.3° (±5%)
Defog Off / On (Auto / Manual)
Flickerless Off / On
Brightness 0 ~ 20 Steps
WDR / BLC OFF / WDR / BLC
Day & Night Auto / Day / Night / Ext-in
HLC Off / On / Night Only
DNR Auto / Off / Low / Middle / High
Mirror Off / H / V / H&V
Sharpness Off / Low / Middle / High / User
White Balance Auto / One Push / Manual / Indoor / Outdoor
Ethernet Ethernet 10/100/1000Base-T (RJ-45)
IP IPv4 / IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2/v3(MIB-2), ARP, DNS, DDNS
ONVIF Yes
